Semiconductor Design & Engineering Services

Powering a High Performance Digital and Mixed-Signal Processing

With over 200+ silicon tape-outs, we have the expertise to deal with increasing complexity of Digital and Mixed/Signal SoC’s design and fuctional verification while ensuring cost reduction and quality semiconductor IP development. eInfochips also offers ASIC / FPGA design, development, prototyping and verification expertise to meet low volume and faster time to market requirements.

Our matured processes and comprehensive checklist have enabled us to execute complex projects in networking, semiconductor AI driven datacenters, consumer devices, automotive, smartphones, multimedia, aerospace, servers, automated test equipment, MEMS, VIP development and EDA tool pre-silicon and post-silicon validation/verification. We have also contributed in development of Verification IPs (VIPs) which are used by leading semiconductor companies worldwide.

Why eInfochips for semiconductor design solutions?

Best in industry execution metrics

Expertise from spec-to-silicon (RTL-GDSII-DFT/DFM Process)

200+ Tape-outs from 180 to 16nm technology nodes

200+ Chip Tape-outs from 180nm to 16nm, 7nm technology nodes

First engineering services company

First engineering services company to tapeout multiple 16nm SoC’s

Expertise across verification disciplines

Expertise across verification disciplines: IP development, Cluster, SoC verification, Formal, Low Power, Mixed signal ASIC

Production ready

Expertise in SystemVerilog, SystemC, C++, Verilog, VHDL, VMM, OVM, UVM

50+ field proven Verification IPs

50+ field proven Verification IPs

Found 100+ bugs in market proven design IPs

Found 100+ bugs in market proven design IPs

Key Offerings

Success Stories

Semiconductor Product Engineering Services Capabilities

Engage for product engineering and semiconductor design services
